2010 Navigator

Description

built in 2010 with a dwt of 2,738 mt, a grt of 1,842, and an nrt of 777. she measures 85.4 m loa with a beam of 16.5 m and a maximum draft of 4.19 m, while the minimum draft is 3.05 m. powered by dual caterpillar 3516 tier 2 engines delivering a total of 5,365 bhp, she achieves a maximum speed of 11.5 kn and a cruising speed of 10 kn. the vessel features dp2 dynamic positioning and is classed abs a1/circle e/ams/dps-2, flying the us flag. her deck spans 2,743.2 m² with a strength of 2.6 t/m², supporting substantial liquid cargo including 598.6 m³ drill/rig water, 1,700.8 m³ liquid mud, and 946.4 m³ fuel, as well as 275.3 m³ potable water. she is equipped with two azimuthing propellers in nozzles and bow thrusters powered by 1,440 bhp, supported by two caterpillar c18 tier 2 generators producing 850 kw each at 460 v/60 hz/3 phase. accommodations include seven air-conditioned and heated staterooms with berthing for 25 personnel, configured in single, double, four-person, and six-person cabins. electronics are extensive, featuring furuno navigation and communication systems, dp2 control, microsoft office, gds idirect vsat, and maptech navigator pro. firefighting capabilities include two remote-controlled monitors with a water capacity of 5,284 gpm at 400 ft, complemented by specialized systems such as sentinel engine alarm, rescue boat, electronic welding machine, blackout prevention system, and rolls royce bps system.
